TL-SF1008L

TL-SF1008L

$29.50

TL-SF1008L is a second-layer managed corridor access switch product specially developed by TP-LINK for residential, campus and other networks. It provides 8 10/100M adaptive RJ45 ports.

SKU: TL-SF1008L
Category:

Description

Hardware specifications

network standards
  • IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x
port
  • 8 10/100Mbps RJ45 ports
indicator light
  • Each port has 1 Link/Ack indicator light
  • Each device has 1 Power indicator light
performance
  • store and forward
  • Supports 8K MAC address table depth
Usage environment
  • Working temperature: 0℃～40℃
  • Storage temperature: -40℃～70℃
  • Working humidity: 10% ~ 90% RH non-condensing
  • Storage humidity: 5% ~ 90% RH non-condensing
Input power
  • 100－240V～ 50/60Hz
Overall dimensions (L×W×H)
  • 250mm×158mm×44mm

Software specifications

Port management
  • Port speed limit
  • Speed/duplex
  • Traffic statistics
QoS
  • Supports port-based, 802.1P priority
  • Supports weight-based, strict priority queue scheduling
VLAN
  • 802.1Q TAG VLAN, Port VLAN
  • Port isolation
User management
  • Port 1 and port 8 have management port functions.
  • client program
  • Support configuration file import/export
security
  • Connection password protection
  • Lightning protection design for uplink port (port 8)
